WObit WDT11-I signalkonditionerare för trådtöjningsgivare 4-20mA
WObit WDT11-I transducer/signalbehandlare för trådtöjningsgivare med 4-20mA utgång och RS485 gränssnitt.
WObit WDT11-I givare 4-20mA för montering på DIN-skena
WObit WDT11-I 4-20mA sidovy
WObit WDT11-I 4-20mA anslutningar botten
WObit WDT11-I 4-20mA terminaler överst

WObit • Signalomvandlare för trådtöjningsgivare, 4-20mA utgång, RS485 gränssnitt

€93,92 Exkl. moms

Varan skickas inom 1-2 arbetsdagar
  Ställa en fråga
Company
WObit E J Ober sc
Polen
Artikelnr: WDT11-I Kategori: Etiketter: , , ,

Konsumentförsäljning



garanti

12

Dela denna produkt med dina vänner:

Beskrivning

WObit • Signalomvandlare för trådtöjningsgivare, 4-20mA utgång, RS485 gränssnitt

WDT11-I är en universell givare för kraftsensorer med trådtöjningsgivare. Tack vare den digitala omvandlaren kan systemet exakt mäta kraften och omvandla den till 4-20 mA och en digital signal (RS485).

Det inbyggda RS485-gränssnittet med MODBUS-protokoll möjliggör direkt kommunikation till en eller flera moduler med en PLC eller HMI-panel. Det är möjligt att ansluta upp till 32 moduler på en buss.

Konfigurationen av modulen görs via USB-porten och den tillhörande programvaran, Förutom enhetsinställningarna kan du också visa de aktuella mätvärdena med programvaran.

Funktioner:

  • Mätning från en trådtöjningsgivare (4 eller 6 trådar)
  • Konvertera värden till valda enheter
  • Konfigurerbar samplingsfrekvens och signalfiltrering
  • Analog utgång: (0)4-20 mA
  • RS485-gränssnitt med MODBUS-protokoll
  • USB-kontakt för konfigurering av enheten
  • Inbyggd knapp och extern tareringskontakt
  • LED-indikering av status
  • Strömförsörjning för enheten 12-24 VDC
  • Montering på DIN-skena eller konsoler

Datablad: WObit_WDT11

Manuell: WObit_WDT11

Standarder



Specifikation

Vikt 0,1 kg
varumärke

WObit
Strömförsörjning

12…24 VDC, < 50mA
Ingångar för kraftgivare

Givarens strömförsörjning: 5V (även 10 V sensorer)
Max. differentialspänning: ±39 mV,
Upplösning: 16 bitar (0,003% FS – för typisk brygga med känslighet 2 mV/V)
Temperaturfel: 0,0025%/C°
Mätfrekvens: max. 123 Hz (4, 10, 33, 50, 62, 123)
Tid för inledande glödgning: ca. 10 minuter
Analog utgång

(0)4-20mA : I min = 3mA (givarfel) , max = 24 mA (överskrider området)
Upplösning: ±0,008 mA, noggrannhet 0,05mA (0,1% FS)
TARA-inmatning

Lågt tillstånd: 0V (max. 1 V), Högt tillstånd: +24 V (5…24 V)
Min. Pulslängd >100 ms,
Gränssnitt

RS485 MODBUS-RTU, (som standard: 38400bps, 8:n:1, adress: 1) USB: 1.1, 2.0
Driftstemperaturområde

5…50°C
IP

IP20
