WObit • SDC107 • DC motor controller, 7A

€83.48 Excl. VAT

MEMIDOS Payment Protection

Delivery Terms: DDU
Item will be shipped in 1-2 business days
  Ask a Question
Company
P.P.H. WObit E.K. Ober s.c.
Poland
SKU: SDC107 Category: Tags: , ,

Consumer sale



Warranty

12

Share this product with your friends:

Description

WObit • SDC107 • DC motor controller, 7A

WObit SDC107 is a controller for DC motors with power up to approximately 150 W.

The driver allows, among others: to control the speed and direction of motor rotation and active reduction of the maximum current consumed by the motor (up to 7 A).

The speed of the motor can be set by an external 0-5V signal or by a built-in potentiometer.

The current limit function allows you to limit the maximum current consumed by the motor and prevent it from overheating or being damaged.

Features:

  • Continuous max. motor current 7 A
  • Adjustable maximum motor current limit
  • Inputs: 0-5V, Start, Direction, Limit+, Limit-
  • Outputs: Error, max. current reached.
  • Built-in potentiometer
  • Opto-isolated inputs
  • LEDs indicating the controller’s operating status
  • Overload and thermal protection
  • Compact housing for DIN rail mounting

Standards



Specification

Weight 0.15 kg
Brand

WObit
Power Supply (voltage)

12…36 VDC
Max. continuous motor current

7 A
Maximum current pulse

20 A / 1 ms
Control inputs

Opto-isolated, Low state 0 V (max. 2 V), high state 5…36 V
Analog input

0-5 V
Outputs: OUT ERR, LIMIT

PNP transistor (source), max. 50 mA
Output OUT BRAKE (brake)

NPN, max. load 2 A
Cooling

Passive
Operating temperature

5°C… 50°C
Mounting

DIN rail
Size

Height: 101 mm
Width: 17,5 mm
Length: 80,5 mm
