EMSYST • EMS41-U • Force sensor with voltage output

255,00351,00 Excl. VAT

Universal membrane load cell with robust construction and voltage output is suitable for industrial use.

Choose the desired configuration:

SKU: N/A Category: Tags: , , , , , ,

Consumer sale



Item will be shipped in 2-3 weeks
  Ask a Question


EMSYST • EMS41-U • Force sensor / Load cell with voltage output

Universal membrane load cell with robust construction is suitable for industrial use. The force must be applied in the axis of the sensor.

The EMS41-U sensor has built-in signal conditioner with voltage output that are calibrated according to industry standards.

The EMS41-U is available in the following models – Rated capacity(Fn): 1kN, 2kN, 5kN, 10kN, 20kN, 50kN

Supported outputs:

Power supply: 5 VDC
• Output: 0,5 – 4,5 V
• Output: 0,5 – 2,5 – 4,5 V (zero shifted to 2.5 V)

Power supply: 24 VDC
• Output: 2 – 10 V
• Output: 2 – 6 – 10 V (zero shifted to 6 V)

Force direction:

  • Tension
  • Compression
  • Tension and Compression (sensors with shifted zero)

See complete datasheet: Datasheet_EMS41

Download .stp models:



Weight N/A
Dimensions N/A
Force range

1kN, 2kN, 5kN, 10kN, 20kN, 50kN

Force direction

Tension, Compression, Tension and Compression


0.5 – 4.5 V (5 VDC), 2 – 10 V (24 VDC), 0.5 – 2.5 – 4.5 V (5 VDC), 2 – 6 – 10 V (24 VDC)



IP Classification
